Panel Cabin 135x135

Height 230 cm
Width 135 cm
Depth 135 cm

Add to Cart

Get a Quote

Technical specifications about the product

Building Height 110/135/210 cm
Wall Insulation wall of 4 mm thickness.
Exterior Door The outer door size is 71.5 x 184.5 and the upper part is 4 mm thick door glass,
Roof System The specially prepared 1.5 mm steel profile
Window It consists of electrostatic powder coated white aluminium profile frames.

Metal Materials ST 37 Galvanized metal profile
Cable 3 x 2.5 TSE certified NYM brand cable was laid on the surface using the electrical wiring duct.
Fuses 16 A TSE certified fuse automat is used.
Roof Insulation insulation with 40 mm thick and 16 kg/m³ density Polystyrene Foam
Glass The windows of the cabin are made of 4 mm thick tempered glass (auto glass)

Highest Insulation

The trapezoidal roof system is built on a steel structure for enhanced durability. Insulation is achieved using 40 mm thick glass wool and polyurethane-filled sandwich panels. A sealing gasket further improves the insulation provided by the polyurethane filling. The ceiling is finished with PVC paneling, offering both functionality and aesthetic appeal.
